TY-DWCWY-01 Human Body Temperature Measurement Thermal Camera

Low temperature thermometer helps to prevent and control COVID-19 epidemic

The first and second generation low temperature thermometer has been widely used in Shandong provincial Party committee, provincial government, provincial military region, provincial public security department, provincial market supervision bureau, Jinan two sessions, Jinan airport, Xinjiang epidemic prevention and control, middle school, University, college entrance examination, senior high school entrance examination, Longao building, Inspur Group, Dong'e Jiao Co., Ltd., Jinan maternal and child health care hospital, Jinan Second People's Hospital, Shandong Xinhang Building Temperature monitoring of COVID-19 epidemic prevention at the entrance and exit , Binzhou financial building, Shiheng special steel and other places.

More than 50 media such as Jinan news comprehensive TV station, China industrial news network, Dazhong daily, people's daily, Wen Zheng Jinan, Shandong Communications Radio and other media carried out tracking reports on the product, and published it on the "learning power" learning platform of the Propaganda Department of the CPC Central Committee. During the epidemic period, millions of cryogenic thermometers were donated to middle schools, universities, governments, enterprises and institutions The equipment has made great contributions to the prevention and control of epidemic situation.

Thermal Body Temperature Measurement Camera Solution ADVANTAGES

Core advantages: At the same time, it supports multi-target (10 people) temperature detection within 5 meters under the condition of - 20 ℃ to 40 ℃, and the temperature measurement accuracy is + / - 0.2 ℃; it supports the real-time uploading of temperature measurement process and value to the network and mobile phone client, and real-time video recording is conducted for 3 months.

Intelligent function: It supports temperature anomaly detection, linkage sound alarm and linkage white light flashing alarm

Thermal imaging function: Uncooled detector, resolution 160 × 120 (default 320 × 240 output), support agc4.0, DDE, 3dnr, dual light fusion image mode, support AI face detection.

Visible light function: 4 million star level 1 / 2.7 inch high performance CMOS; maximum resolution up to 2688 × 1520@25fps Visible light supports low bit rate, low delay and ROI enhancement coding, supports 3D digital noise reduction and supports 120dB wide dynamic.

Infrared related: support smart IR, support the opening and closing of over exposure of light supplement, support automatic and manual control under the opening, manually support the brightness control of fill light according to distance level, support independent configuration of two sets of parameters day and night, and support temperature detection within 5 meters under low temperature.

Low temperature thermometer TECHNICAL PARAMETER

Model parameters TY—DWCWY—01

Low temperature thermometer

Thermal imaging Sensor type Uncooled vanadium oxide detector

Maximum image size 160× 120（default 320 × 240 output）

pixel size 17μm

NETD ≤ 40mk(@25°C,F#=1.0)

Focal length of thermal imaging   lens 6mm

MRAD 2.74

Field of view angle of thermal   imaging 25°×18.7

Close range of thermal imaging 1.1m

visible light Sensor type 400 Ten thousand stars1/2.7"

Progressive Scan CMOS

resolving power 2688×1520@25fps

Minimum illumination 0.005Lux @(F1.2,AGC

ON) ,0 Lux with IR

shutter 1/3s-1/100000s

Intelligent function Linkage alarm Support linkage white light alarm，Support linkage sound   alarm

Temperature measurement function Abnormal temperature function Expert mode of full screen temperature   measurement：10   points, 10 frames, 1 line, 21 temperature measurement rules in total

Body temperature measurement Support AI face detection, multi-target detection of body   temperature at the same time

Temperature measurement alarm Built in loudspeaker, the body temperature   is too high to trigger
