Zinc-Aluminum (Galfan or Bezinal) 358 High Security Mesh with Channel Posts, Rails and Concertina Razor Barbed Tape

We supply the following standard 358 high security mesh made of Zinc-Aluminum (Galfan or Bezinal) wire. Fitted with channel posts, rails and short barb concertina wire. Also similar standard items for export. 358 high security mesh is also known as 358 secure mesh, secure net or securi mesh.

Black Powder Coated Steel Wire Mesh High Security Fencing Sheet

358 Secure Mesh (75x16mm aperture)

Specification

Wire: Ø 4mm Zinc-Alu drawn wire (Galfan or Bezinal); wire diameter tolerance: +/- 0.08mm

Transversal (horizontal) wires: 13mm centres

Longitudinal (vertical wires): 75mm centres

Aperture: 75mm x 16mm

Wire resistance welded at each intersection.

Tensile Strength: 500-625 MPA.

Zinc Coating Mass: 265 gm2

Panels size:

2100mm height x 2404mm length sheet

2384mm height x 2404mm length sheet

2700mm height x 2404mm length sheet

Y-Post for Concertina Wire Support

Square Opening Mesh Panels

Uneven Channel Posts:

Size 50x115x30x4mm, 5.6kg/M (3000mm long), 350MPa, channel post with section depth 115mm; Flange width 51 & 30mm; Material thickness 4mm;

Size 50x115x30x4mm, 5.6kg/M (3300mm long), 350MPa, channel post section depth 115mm; Flange width 51 & 30mm; Material thickness 4mm;

Size 50x115x30x4mm, 5.6kg/M (3600mm long), 350MPa, channel post section depth 115mm; Flange width 51 & 30mm; Material thickness 4mm;

Size 50x115x30x4mm, 5.6kg/M (3900mm long), 350MPa, channel post with section depth 115mm; Flange width 51 & 30mm; Material thickness 4mm.

I-beam Fence Posts:

100UC x ~14.8kg/M (3000mm long): Section depth 97mm; Flange width 99mm; Thickness 7mm

100UC x ~14.8kg/M (3300mm long): Section depth 97mm; Flange width 99mm; Thickness 7mm

100UC x ~14.8kg/M (3600mm long) : Section depth 97mm; Flange width 99mm; Thickness 7mm

100UC x ~14.8kg/M (3900mm long) :Section depth 97mm; Flange width 99mm; Thickness 7mm

Rails:

50x50x4mm (2411mm long) 250MPa with 8 x 9mm slots

Other Fittings:

M12 x 30 Cup Head Bolt 8.8 Grade

M12 Shear Nut Class 8

M12 washer

M8 x 40 Cup Head Bolt 8.8 Grade

M8 x 30 Cup Head Bolt 8.8 Grade

M8 Shear Nut Class 8

M8 washer

550mm Concertina razor tape

Concertina Wire with Short Razor Type Barbs

Together with products, we will provide following technical informations and certificate of testing of wire materials, posts, according to international standards.
