DLJCS-Z3040B

Intelligent Radial Drilling Machine Electric Skill Training Appraisal Assessment Device (Semi-real object)

1. Function feature

1, Z3040 type radial drilling machine semi-real model is designed according to dimension of the actual physical Z3040 universal milling machine according to certain proportion reduced.

2, All motor voltage grade in the physical model is the completely same with the actual machine.

3, The lathe bed of semi-real machine tool use casting, special die once moldings, ball screw drive, the hand wheel using practical machine tool parts, close to the real machine tools.

4, Semi-real machine tool parts adopt different color, when training, make students more easy to understand accept.

5, Semi-real machine tool activity guide surface with high frequency quenching process and durable.

6, The operation of the electric parts device, can realize Z3040 type radial drilling machine semi-real all kinds of motion control, including: Master shaft and reversing, spindle high or low speed operation, the work bench horizontal fast moving, protect safety of the limit position.

2. Technical Feature

1, Input power: Three-phase five wire (380V± 10% 50Hz)

2, Work environment: Temperature-10 ° C ~ + 40 ° C, relative humidity < 85% (25 ° C) height < 4000 m

3, Device capacity: < 1 KVA

4, Dimension: 1500 x 700 x 1720 mm (long x width × High)

5, Work move stroke: 200 mm

6, Spindle speed stroke: 250r/min

4. Product range:

1) Electrical technology Know-how Training Set

2) Innovative E-skills &Technology Training Series

3) MCU Technology Training Series

4) Machine Tools Electrical Control Training Series

5) Machine Tools Electrical Control Training Series(Model-type)

6) CNC Machine Tools Maintainance Training Series(Model-type)

7) Building Automatic Training Series

8) PC Training Series

9) Innovative industrial Automatic Control Technology Training Series

10) Pneumatic Training Series

11) Hydraulic Training Series

12) Sensor Training Series

13) Motor Training Series

14) Mechatronic Training Series

15) MPS Training Series

16) FMS Training Series

17) Mechanical Training Series

18) Engrave Machine Series

5. Packaging And Delivery Details:

Packaging Detail:

1). Packaging for training kit: Plastic package + carton + plywood pallets

2). Packaging for training equipment: Plastic package + plywood pallet

Delivery Detail: 40 to 50 days after Received advanced payment.

6. After-Service And Training for Foreign User

1) For our exported equipments, the Warranty is one year, within one year, if there is any problem for spare parts(except damage by man-made) We can supply and replace free of charge. And if after one year, we also supply the service. The difference is user need to pay it.

2) We dispatch our professional and experienced engineer to install equipments and make training
