CR123ASE Primary Lithium Manganese Dioxide Batteries Bobbin Type Small Lithium Battery Non-Rechargeable Lithium Batteries 800mAh For Non-rechargeable Gas Meter NB-IoT Meter.

Details of CR123ASE Li Mno2 Primary Battery

Product Details of CR123ASE Li-MnO2 Cylindrical Battery

Place of Origin China

Brand Name HCB

Certification UN/CE/RoHS/UL

Model Number CR17335SE/CR123ASE

Payment & Shipping Terms Details of CR123ASE Li-MnO2 Cylindrical Battery

Minimum Order Quantity 1K pcs

Price Negotiable

Packaging Details Special design for Air/Sea/Courier transportation

Delivery Time 5 workdays

Payment Terms T/T, L/C, D/A, L/C, Western Union, MoneyGram

Supply Ability Two million unit per month

Advantage of CR123ASE Li-MnO2 Cylindrical Battery

High voltage response, stable during most of the lifetime of the application

Energy density for the lithium manganese dioxide battery up to 830Wh/L

Wide operating temperature range (-40℃~+85℃)

Low self-discharge rate (less than 1% per year after 1 year of storage at +25℃)

Specification of CR123ASE Li-MnO2 Cylindrical Battery

Electrical characteristics Open circuit voltage (at 25°C) ≥3.10V

Nominal capacity 1800mAh

(At +25°C,battery discharged at continuous current 1mA until voltage reaches cut-off voltage 2.0V. The capacity can vary at different temperature, discharge current or cut-off voltage.)

Maximum continuous current 10mA

(At +25°C, 2.0V cut-off, battery discharged for minimum 50% of rated capacity.)

Maximum pulse discharge current 100mA

(At +25°C, 2.0V cut-off, battery discharged for minimum 50% of rated capacity with max pulse for 3 seconds after 27 seconds break. The discharged capacity may vary according to the pulse characteristics, the temperature, and the cell’s previous history. Fitting the cell with a capacitor may be recommended in severe conditions, consult HCB.)

Storage (recommended) ≤+30°C

(For more severe conditions, consult HCB) ≤75%RH

Operating temperature range -40°C~+85°C

(Operation above ambient temperature may lead to reduced

capacity and lower voltage readings at the beginning of pulses, consult HCB.)

Physical characteristics Diameter 16.6±0.2mm

Typical weight 22.0g

Li metal content 0.56g

Use Warning of CR123ASE Li-MnO2 Cylindrical Battery

This battery is a non-rechargeable battery.

DO NOT CHARGE THE BATTERY! When this battery is charged, gas is generated inside and raises internal pressure, resulting in fire, heat generation, leakage, or bursting.
