HZSP FOG DAMPENER

Flour Milling Machinery

HZSP

FOG DAMPENER

•Fog dampener is a special-purpose equipment used for micro dampening before milling. It atomizes water into tiny drops under 100 micrometer, and adds water to wheat epidermis uniformly. On the premise that it doesn’ t increase wheat germ’ s water content, it increases epidermis' water content, softens bran, improves epidermis fiber' s resistance against mechanical damage. Thus, during milling, bran can be kept complete, bran content in flour drops, flour is whitened, flour' s ash content is reduced and finished product quality is improved.

•It can also be used for the fog dampening in rice polishing, and the adding of oil/grease and liquid and water-soluble microelements in animal feed.

•Electric atomizing technique

•Uniform wheat dampening

•No air compressor is needed, eradicating wheat pollution caused by compressor’ s lubricating oil.

•Auto stop of power supply and water supply for protection in case of wheat discontinuance or jam can ensure fog dampener’ s normal and effective work.

Model Capacity (t/h) Power (kw) Weight (kg) Dimension (mm)

HZSP 20-300 3 0.05 32 570 × 450× 470

HZSP 25-300 4 0.05 42 640 × 450 × 640

HZSP 50-300 8 0.1 48 700 × 520 × 700

HZSP 50-380 10 0.1 62 770 × 580 × 870

HZSP 75-380 15 0.2 65 770 × 580 × 870

HZSP 100-380 20 0.2 98 800 × 580 ×1350

HZSP 150-380 30 0.3 130 800 × 580 × 1350

HZSP 50-740 50 0.37 200 1200 × 900 × 2050
