Double Layer Press Belts

Double Layer Press Felts include 1+1 composite structure and double layer of MD yarn structure. The 1+1 composite structure consists of two layer base meshes of different thickness. Both of these base meshes can be changed in construction and sizes to suit the requirements of different paper machines. Double layer felts have the features of high press resistance, good flexibility, permeability and size stability, less elongation, excellent tensile strength. The felts are also resistant to vacuum marks, blind hole marks, groove marks etc. Double layer BOM felts are used in press types such as: groove press, vacuum suction press, multi-press, large diameter nip-roll press to produce high grade printing papers, news-prints, technical papers, packaging papers, high grade paper boards etc.

Double Layer Press Felts

Paper Grade：≥8g/m2

NIP：60~200kN/m

GSM: 950~1450g/m2

Felt GSM Tolerance：≤±4%

Air Permeability：30~110cfm

Tensile Strength：≥3000N/5cm

Elongation Percentage：≤0.6%

Width Variation：≤±2cm

Type GSM Structure Application

47501 950~1300 double layer mesh corrugating papers, kraft papers, packaging papers

47502 1000~1100 double layer mesh corrugating papers, kraft papers, packaging papers

47504 900~1100 double layer mesh corrugating papers, kraft papers, packaging papers

47505 1100~1400 double layer mesh writing & printing papers, newsprints, packaging papers, kraft papers

47521 950~1300 double layer mesh corrugating papers, kraft papers, packaging papers

47522 1000~1100 double layer mesh kraft papers, papers boards

47523 1200~1500 double layer mesh writing & printing papers, newsprints, packaging papers, kraft papers

47524 900~1100 double layer mesh corrugating papers, kraft papers, packaging papers

47525 1200~1500 double layer mesh big roll press for high-grade, packaging papers, papers borads

Double layer BOM felts are used in press types such as groove press, vacuum suction press, multi-press, large diameter nip-roll press to produce high grade printing papers, news-prints, technical papers, packaging papers, high grade paper boards etc
