Our company Jwell is professional at pp pipe extrusion machine and other kinds of plastic PVC HDPE RTP PPR Corrugated pp pipe making machine for over 25 years, and has ranked first in the extrusion industry for 11 consecutive years in China, exporting more than 3000 sets high quality plastic pipe profile machine to over 120 countries and areas every year.

PP pipe has the features of non-toxic, sanitary, non rusting, wear resistance, no scale, reduced vibration, low noise, anti freezing cracking, high temperature resistant, recyclable, simple installation, and long service life, which is mainly used in indoor hot and cold water supply system and is also widely used in heating system. The connection methods include welding method, end edge welding method and different material connecting pipe.

Advantages of PP Pipe Extrusion Line

03.

The pipe mould is made by high hardness alloy steel. The inner flow channel has been chrome plated and highly polished to ensure good pipe shape.

04.

Intelligent SIEMENS computer control system to help you know detailed data of each part of this machine line in real time.

05.

Chipless cutter adopts a rotating clamping device so that operators don't need to replace the fixture for different pipe diameters.

06.

Equipped with many safe devices to prevent your workers from being injured during pipe production process.

Specification of PP Pipe Extrusion Line

Model Pipe Spec (mm) Extruder Main Power(kw) Output (kg/h)

JWPEG-H63 Ø16-Ø63 JWS-H 60/40 90 400

JWPEG-H110 Ø20-Ø110 JWS-H 60/40 110 450

JWPEG-H160 Ø50-Ø160 JWS-H 75/38 132 500

JWPEG-H250 Ø75-Ø250 JWS-H 75/38 160 650

JWPEG-H315 Ø110-Ø315 JWS-H 75/38 160 700

JWPEG-H450 Ø160-Ø450 JWS-H 90/38 250 950

JWPEG-H630 Ø315-Ø630 JWS-H 90/38 280 1050

Details of PP Pipe Extruder

Cooling Tank

Bran-new 304 stainless steel tank

Dense spray for faster and stable cooling

Equipped with several measuring meters to detect the water level and pressure in the tank in real time

Haul off

Caterpillar type haul off with independent motor to drive

Pneumatic pressing

Equipped with accurate encoder to measure the length

Cutter

Steel alloy material, more durable

Dust free, fast and low noise
