GZPTS-D Series of High Speed Double-slides Tablet Press Machine

CNC মেশিন

অনুরোধ করলে

এক্সপ্লোর পরিচালনা

পাওয়া গেল না

পাওয়া গেল না

জিজ্ঞাসা করা

পণ্যের বিবরণ

GZPTS-D series high-speed double-slides tablet press machine adopts advanced modular design concept, simple structure, and easy maintenance. The servo motor is used for the main pressure and filling. The tablet manufacturing machine has fast reaction speed and high adjust accuracy. Large visual tablet space makes cleaning and operation more convenient.

Specification of GZPTS-D Series of High Speed Double-slides Tablet Press Machine

Model GZPTS-D 49 61 73 79

Punch & Die Type (EU) D B BB BBS

Punches Number 49 61 73 79

Max Tablet Diameter (MM) 25 16 13 11

Max Abnormal Prelate Axis Size (MM) 25 18 16 13

Max Output (Tablet/h) 470400 585600 700800 758400

Max Filling Depth (MM) 18 18 18 18

Max Main Pressure (KN) 100 100 100 100

Max Pre Pressure (KN) 100 100 100 100

Idle Load Noise dB (A)
