Smart Card Custom NXP MIFARE 1K CARD

Specifications

Product Name: Smart Card

Card size: 86x54mm (Customized Available）

Antenna size: 75x45mm(HF)/dia45mm(LF)/UHF(Alien9662 inlay)

Thickness: 0.80+/-0.04mm(HF&UHF),0.88+/-0.04mm(LF)

Material: PVC/PET

ISO: ISO7816

Printable: Printable with offset, silkscreen, personalizing on the PVC;

Feature: Waterproof

Read Range: 0~75px(Depends on reader)

Working Temp: " -20°C to 50°C"

Chip optional: "LF:EM4200/TK4100/T5577/HID,etc

HF:NXPS20/ntag203/ultralight/ultralight C/S50/S70/ICode2/ICODE-S/Desfire series,etc

UHF :Alien H3&Monza4

Contactless Smart Card Additional Crafts

Injet/thermal/laser/barcode/QR code printed UID numbers or serial numbers;

Mag-stripe at backside(300oe/2750 oe/4000 oe)

Signature panel (White, grey and transparent)

counterfeiting technology(encoding, hologram, water mark, micro-text, etc)

Silver/golden metallic background

Others (embossing, gold/silver blocking, epoxy, etc)

Production Package

Packing into opp bags, 200pcs/inner box,10boxes/carton;

Box's size:21x9x150px,Carton's size:50x25x12CM

Net/Gross Weight: 13/13.3KGS per carton;

Applications

access control solution card

Parking lot

NFC Payment

Hotel Door Lock

Transpotation

Highway Toll

Membership
