B.S.3032 Large Dee Shackle with Screw Collar Pin

B.S.3032 Large Dee Shackle with Screw Collar Pin, also known as Large Dee Shackle to B.S.3032 with Type A Screw Collar Pin.

The Large Dee Shackles are to BS-3032 Specification and have a Screwed Collared Pin.

This popular shackle is used throughout various industries in the UK and beyond. Predominantly used in the industrial and construction markets as a load rated lifting shackle, they are also very prevalent in marine mooring applications. By far the most popular shackle types are Dee and Bow shackles with a screw pin (type A pin).

Available Size for Large Dee Shackle to B.S.3032 with Type A Screw Collar Pin: 1/4″, 3/8″, 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1-1/8″, 1-1/4″, 1-3/8″, 1-1/2″.

Information of B.S.3032 Large D Shackle with Screw Collar Pin

Technical Notes Bow shackle conforms to B.S. 3032

Materila Carbon Steel

Processing Forged / Quenched and Tempered

Finish Hot Dip Galvanized, Zinc Plated or Self Colored

Size 3/8″, 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1-1/8″, 1-1/4″, 1-3/8″, 1-1/2″, 1-5/8″

Notes Working Load Limit Permanently Shown on Every Shackle.

Typical Applications a.General lifting in off-shore applications. b.General lifting and tethering in leisure marine applications.

c.General lifting purposes.

Specifications of B.S.3032 Large Dee Shackle with Screw Collar Pin

Part No. A B C D E Weight SWL

Inches Inches Inches Inches Inches Kgs/Each Tonns

LGBS3032LD01 1/4″ 3/8″ 1/2″ 1 3/4″ 0.1 0.25

LGBS3032LD02 3/8″ 1/2″ 3/4″ 1 1/2 1 0.12 0.5

LGBS3032LD03 1/2″ 5/8″ 1 1/8 2 1/8 1 1/4 0.29 0.75

LGBS3032LD04 5/8″ 3/4″ 1 1/4 2 1/2 1 1/2 0.57 1.5

LGBS3032LD05 3/4″ 7/8″ 1 1/2 2 7/8 1 3/4 0.92 2

LGBS3032LD06 7/8″ 1 1 3/4 3 1/4 2 1.59 3

LGBS3032LD07 1 1 1/8 2 3 3/4 2 1/4 2.12 3.75

LGBS3032LD08 1 1/8 1 1/4 2 1/8 4 1/8 2 1/2 3.18 5

LGBS3032LD09 1 1/4 1 3/8 2 3/8 4 1/2 2 3/4 4.54 6

LGBS3032LD10 1 3/8 1 1/2 2 5/8 5 3 6.06 7

LGBS3032LD11 1 1/2 1 3/4 2 3/4 5 3/8 3 1/2 8.74 9.5
