This is the Custom 4 Axis Machining Parts recently produced by us.

It meets the requirements of ISO9001: 2008.

Specification: 43mm*49mm

Raw material: AL6061-T6

Surface Treatment: clear anodizing

Finish: anodizing

Specifications of Custom 4 Axis CNC Machining Parts

Type Diaphragm coupling model Diameter(D) Diameter of the inner hole (Accept customization) Length(L)

Type: Broaching, Drilling, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Rapid Prototyping, Turning, Wire EDM Material Capabilities: Aluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel Alloys, plastic

Micro Machining or Not: Micro Machining Model Number: OEM

Size: 43mm*49mm Material: AL6061-T6

Main Process: Aluminum CNC milling Surface treatment: Clear anodizing

Tolerance: +/-0.005mm Supply Ability 1,000,000 Pieces per Month

Different Diaphragm Coupling of Custom 4 Axis CNC Machining Parts

Type Diaphragm coupling model Diameter(D) Diameter of inner hole (Accept customization) Length(L)

Double diaphragm coupling SH-CPDW 19 4 5 6 7 8 27

25 6 6.35 8 10 11 12 31

32 8 10 11 12 14 15 40

40 8 10 11 12 14 15 16 17 18 19 20 44

50 14 15 16 17 18 19 20 22 24 25 57

SH-CPDD 32 6 8 10 40

40 8 10 11 12 14 46

50 12 14 15 16 18 19 20 52

63 15 16 18 19 20 25 58

Single diaphragm coupling SH-CPDW 19 4 5 6 7 8 20

25 6 6.35 8 10 11 12 24

32 8 10 11 12 14 15 29

40 8 10 11 12 14 15 16 17 18 19 20 33

50 14 15 16 17 18 19 20 22 24 25 42

SH-CPDS 32 8 10 11 12 14 15 32

40 8 10 11 12 14 15 16 17 18 19 20 38

50 12 14 15 16 18 19 20 44

63 14 15 16 17 18 19 20 22 24 25 50

As one of cnc machine parts suppliers, we can offer kinds of cnc machining parts for sale, anything you need, please contact us.
