SN-IPV57/80ECDR/B

1/1.7” progressive scan CMOS

20fps @ 12MP(4000×3000)

Multiple de-warping mode

Image distortion correction

Support camera & software de-warping

DWDR, 3D DNR, ROI, Defog, HLC,IVS

Smart IR up to 15 m

IP66

Camera

Image Sensor 1/1.7” Progressive Scan CMOS

Effective Pixels 4000(H)×3000(V)

Electronic Shutter Auto/Manual, 1/5 ~ 1/20,000s

Min. illumination Color: 0.009 Lux @ (F1.2,AGC ON)

B/W: 0 Lux @ (IR LED ON)

S/N Ratio 55dB

Day/Night Auto(ICR)

Wide Dynamic Range DWDR

IR Range Up to 15 m (49.2 ft)

IR On/Off Control Auto/ Manual

Lens

Lens Type Fixed

Iris Fixed Iris

Focal Length 1.83 mm

F Number F2.4

Angle of View 180°×180°

Focus Control Fixed

Video

Max. Resolution 12MP (4000×3000)

Streaming Capability 2 Streams

Stream/Frame Rate Stream1: 4000×3000 @20fps, 4096×2160, 3840×2160, 3000×3000, 2560×2560, 1920×1080 @25/30fps

Stream2: 1280×960, D1, 720×720 @25/30fps

Bit Rate Control CBR/VBR

Bit Rate Stream1: 500kbps~16000kbps

Stream2: 100kbps~8000kbps

Image Enhancement HLC/BLC/Defog

White Balance Auto

Gain Control Auto/Manual

Mirror Support

Noise Reduction 2D/3D DNR

Aisle Mode Support

Region of Interest Off/On (8 Zone, Rectangle)

Motion Detection Support

Privacy Masking Support

Audio

Compression G.711, RAW_PCM

Bit Rate 8kbps, 16kps, 64kbps

Network

Protocols IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP, TLS/SSL

Interoperability ONVIF, SDK, CGI

Streaming Method Unicast

Max. User Access 10 Users

Web Viewer
