EPS Color Steel Sandwich Panel Machine

PRODUCT DESCRIPTION

EPS(ROCK WOOL)/COLOR STEEL SANDWICH PANEL PRODUCTION LINE

Components for the full sandwich panel production line

Standard Decoilers

For use pre-painted galvanized steel coil sheet up to 5 tons in weight. The coil holder is supplied with two supporting wood and expanding mandrels.

Coil Guiding equipment

When the coil sheet come the laminator, the guiding system ensures the sheet to the correct position.

Pre-heating system

Before glue scraping, the coil sheet will be heated in this system.

Guiding roller core

When the EPS fed to the machine, the guiding roller will guide the EPS to the laminating cabinet, the roller core will go the cabinet too. This makes the EPS closer to the top and lower coil sheet, thus make the finished panel more solid.

Glue Providing

There are 4 drum stand, with proportion at 60:40 (the glue is provided by the buyer, and the quality shall be meet the speed at 3-4 meters per minute). The glue will scraping at 4 directions, this guarantees the glue can be supplied at different speed.

This part is operated separately.

Glue Filling Pad

The pad is in to-and-fro movement, there are air cushions on the concrete pad.

Heater

To open the heating pipe or not and how many pipes to open, is depend on the temperature and the solidify time of glue. The heater is to heat the top and lower coil sheet at appropriate temperature in laminating

Cutting system ( for laminating use )

In production, when the sandwich panel meets the set length, the system will cut the panel with milling cutter.
