High Precision TCXO: The Ultimate Solution for Accurate Frequency Control

Introduction to High Precision TCXO

In the realm of advanced technology, achieving precise frequency control is paramount. A high temperature oscillator stands out as a critical component, delivering exceptional frequency stability and accuracy across varying temperatures. Designed for high-stakes applications such as GPS, telecommunications, and instrumentation, a high precision oscillator ensures reliable performance and minimal drift, making it indispensable for environments that demand stringent timing precision and robust operational consistency.

What is a High Precision TCXO?

A High Precision TCXO is a specialized oscillator that uses temperature compensation technology to maintain stable frequency output despite changes in environmental conditions. This advanced technology makes TCXOs ideal for applications where timing accuracy is crucial.

Exceptional Frequency Stability: Maintains consistent performance across a wide range of temperatures.

Advanced Temperature Compensation: Ensures minimal frequency drift, even in fluctuating environmental conditions.

Critical Applications: Perfect for GPS, telecommunications, and instrumentation.

High Precision TCXO Types

BT3225_RTC

LTE,BTS,CATV, LAN,GPS Tracking, Test&Measurement Equipment

BT3225B_DIFFERENTIAL

LTE,BTS,CATV, LAN,GPS Tracking, Test&Measurement Equipment

BT0503A

Features：High Temperature Stability, Low Phase Noise,Analog Circuit

Dimensions: 5.0x3.2mm

Freq. Range：10~52MHz

Freq. Stability Range：±0.05~±0.5ppm

Operating Temperature：-40~85℃

Phase Noise：-150dbc@1KHz

BT0503C

Dimensions: 5.0x3.2mm

Freq. Range: 10~52MHz

Freq. Stability Over Temp.: ±0.1~±0.5ppm@-40~85℃

Phase Noise: -140dBc/1kHz@10MHz

BT0503D/E

Dimensions: 5.0x3.2mm

Freq. Range：10~60MHz

Freq. Stability Over Temp.：±0.28~±1.5ppm@-40~85℃

Phase Noise：-140dBc/1kHz@10MHz

BT0507A/B

Dimensions: 7.0x5.0mm

Freq. Range: 10~52MHz

Freq. Stability Over Temp.: ±0.05~±1.0ppm@-40~85℃

Phase Noise: -142dBc/1kHz@10MHz
