Applications

For water supply from wells or reservoirs

For domestic use,for civil and industrial applications

For garden and irrigation

Operating conditions

Maximum fluid temperature up to +35℃.

Maximum sand content : 0.5％.

Maximum immersion : 100m.

Minimum well diameter : 6＂.

Motor and pump

Rewindable motor or Hermetically-Sealed motor

Single-phase : 220V- 240V /50HZ

Three-phase : 380V - 415V /50HZ

①Direct start（1 cable)

②Star-delta start (2 cables)

Equip with start control box or digital auto-control box

NEMA dimension standards

Curve tolerance according to ISO 9906

Options on request

Special mechanical seal

Other voltages or frequency 60 HZ

Warranty : 2 years

(according to our general sales conditions).
