Overview of G320 Gas leakage SF6 camera

G320 adopts cooled QWIP detector, it can accurately find the SF6 leakage point. This portable thermal imaging camera for leak detection can detect the leakage from a safe distance, thus the safety of operators can be ensured. It can also track some gases harmful to the environment, which has environmental benefits.

Features of G320 Thermal Imaging Camera

Cooled QWIP SF6 gas leak detector, sensitivity ≤0.025℃

SF6 gas leakage measurement sensitivity≤0.001ml/s

Passive infrared imaging, no specific background or auxiliary light source is required

It can be used for sf6 leak detection and thermal temperature measurement

Pictures and videos are stored in SD card directly

Built-in 5.0 MP digital camera

It is small in size and weighs only 2.6kg

sturdy and durable, intelligent operation

Technical Specifications of G320 Thermal Imaging Camera

Item G320

Detector Data

Type Cooled QWIP

IR resolution 320X256

Pixel pitch 30μm

Spectral range 10.3~10.7μm

NETD/Sensitivity 25mK

Gas sensitivity ≤0.001ml/s

Lens Data

FOV/Focal distance 10°×7.5°/55mm

Minimum Imaging distance 1m

IFOV 0.55mrad

Focus Manual

Image Performance

Applications of G320 SF6 Gas Leak Detection Camera

Electricity

Chemical Industry

Environmental organization

Research Institute
